High-Performance Processor: Rockchip RK3399 6-core 64-bit processor.
Advanced Graphics: Mali-T860 MP4 4-core image processor.
Dual OS Support: Compatible with Android and Ubuntu systems.
Durable Design: Aluminum-magnesium alloy box with IP65-rated front panel.
Versatile Power Input: Wide voltage range from DC 12V to 24V.
LAN: 1×10/100/1000Mbps Ethernet, 1×RJ45 Ethernet (optional), onboard WiFi (2.4G, WiFi 802.11b/g/n), Bluetooth 5.0
USB: 3×USB3.0, 1×USB2.0
COM: 3×RS232 (DB9); COM1/COM2 configurable for RS485 (default: COM1 RS485, COM2 RS232)
Audio: 2×3.5mm speaker interfaces (8Ω, 6W)
OTG: 1×USB3.0 OTG
Key: 1×Return
HDMI: 1×HDMI, supports 4K@60Hz, HDCP 1.4/2.2.2
Dimensions: 215mm × 147mm × 39.8mm
Weight: 1.66kg
Box Structure: Aluminum-magnesium alloy, fanless
Mount: Wall-mounted
OS: Android 7.1.2
Operating Temperature: -20°C ~ 70°C
Storage Temperature: -40°C ~ 80°C
Shock: SSD applied, 10G, IEC 60068-2-64, Half sine wave, 11ms duration
EMC: CE/FCC Class B
