LAN: 1 x Intel I211AT GbE LAN controller, 2 x RTL8111H GbE LAN controllers
USB: 2 x USB on the front, 1 x USB2.0 onboard for USB dongle
COM: 1 x RS232, 1 x RS485
Additional I/O: 1 x Programmable LED, 1 x Programmable Switch, 1 x DI, 1 x DO
Expansion: 1 x miniPCIe expansion slot, supports Wi-Fi, 3G/4G modules
Mounting: Wall-mounted or DIN-Rail fixing style
Temperature: Wide operating temperature range of -20 ~ 60℃ supported
LAN: 1 x Intel GbE LAN controller, 2 x RTL GbE LAN controllers
USB: J1900: 1 x USB3.0, 1 x USB2.0 / J6412: 2 x USB3.0, 1 x USB2.0 Type A on board for USB dongle
COM: 1 x RS232, 2 x RS485
DI: 1 x DI; 1 x Programmable Switch
DO: 1 x DO (transistor output); 1 x Programmable LED
CAN: 2 x CAN Bus 2.0A/B
DP: Supports up to 3840 x 2160
VGA: Supports up to 1920 x 1200 (optional)
HDMI: J1900: Supports up to 1920 x 1080 / J6412: Supports up to 4096 x 2160
Dimensions: (L)160mm x (W)122.7mm x (H)45mm
Weight: 1.06 Kg
Box Structure: Aluminum-magnesium alloy BOX, fanless
Cooling System: Fan embedded to assist cooling
Mount: Fanless
Input Voltage: DC12/24V ±10%, with overcurrent, overvoltage, and polarity inverse protection
Microsoft Windows: Windows 10
Linux: Ubuntu
Work Temperature: -20ºC ~ 60ºC with airflow (SSD)
Storage Temperature: 40ºC ~80ºC
Relative Humidity: 5~95% (non condensing)
Vibration: 5500Hz, 1.5Grms @ with SSD, Follow IEC60068-2-64
Shock: 20G peak acceleration (11ms duration) with SSD, Follow IEC60068-2-27
EMC: CE/FCC Class A
