Processors: Supports Intel® Core™ 6th–9th Gen CPUs; NP-6135 supports Intel® Core™ 10th–11th Gen CPUs.
Networking: Dual Intel GbE LAN controllers for reliable connectivity.
I/O Ports: 4 x USB3.0, 1 x USB2.0; 2 x RS232/RS485 with auto flow control.
Display: Compatible with VGA and HDMI ports.
Expansion: 1 x miniPCIe for WiFi, 3G/4G modules.
Power Supply: DC12–24V with protection features.
Durability: Wall-mounted or DIN-Rail support; operating temperature from -20°C to 60°C.
CPU: NP-6125 supports Intel® Core™ 6th–9th Gen; NP-6135 supports Intel® Core™ 10th–11th Gen.
Memory: 2 x SO-DIMM DDR4-2400MHz, max 32GB.
Storage Medium: 1 x mSATA bay; 1 x M.2 (B Key, Type 2280)
Expansion MiniPCIe: 1 full-size PCIe Mini slot with SIM card holder (USB signal).
Optional Expansion: Nine options, including CAN2, 8POE, and HDD.
LAN: 2 x Intel GbE.
USB: 4 x USB3.0, 1 x USB2.0 Type A.
COM: 2 x RS232/RS485 (auto flow control, ESD protected).
VGA: Up to 1920 x 1080@60Hz.
HDMI: Up to 3840 x 2160@60Hz.
Dimensions: 200mm x 154.5mm x 57.6mm.
Weight: 1.9 Kg.
Structure: Aluminum-magnesium alloy box with embedded fan for cooling.
Mounting: Wall or DIN-Rail.
Input Voltage: DC12–24V ±10%, with protections; DC24V required for light control functionalities.
Support: Windows 10 IoT, Ubuntu, CentOS, Debian.
Operating Temperature: -20 ~ 60°C (-4 ~ 140°F) with airflow (mSATA).
Storage Temperature: -40 ~ 80°C (-40 ~ 176°F) with airflow (mSATA).
Humidity: 5–95% (non-condensing).
Vibration: 5–500Hz, 1.5Grms@SSD (IEC60068-2-64).
Shock: 20G peak acceleration (IEC60068-2-27).
EMC: CE/FCC Class A.
WatchDog: 1–255 levels programmable.
Remote ON-OFF: 1 input.
