Aluminum panel with IP65 compliant
Ecrã tátil capacitivo 15.6″ XGA TFT, com resolução 1366*768/1920*1080
Support Intel® the 6th – 11th Gen. Core™i3/i5/i7, Pentium, Celeron LGA1151 socket CPU
3x Gigabit Ethernet ports
4 x RS-232 / RS-485 Interface with surge protection, RS485 support automatic flow control
Wide voltage DC12~24V input, reverse polarity protection, overvoltage protection, overcurrent protection
Extend WIFI/3G/4G network from Mini-PCIe slot
I/O: HDMI/ 3GLAN /6USB / 4COM
LAN: 3×Intel 10/100/1000Mbps controller
USB: 4×USB3.0 / 2 x USB2.0
COM: 4×RS-232 / RS-485 Interface with surge protection, RS485 support automatic flow control
DI: 8DI+8DO, Wet contact input(24V), OC gate output (24V 300mA)
DO: 8DI+8DO, Wet contact input(24V), OC gate output (24V 300mA)
Rear I/O: 3 x GLAN / 6 x USB / 4 x COM /1x HDMI
LCD: 15.6″ XGA TFT
Resolução: 1366 x 768/1920 x 1080
Cor: 16.7MB
Active Area: 344.232mm x 193.536mm/344.16mm×193.59mm
Backlight: LED
MTBF: 50000hrs/15000hrs
Pixel Pitch: 0.252 x 0.252//0.179×0.179
Luminância: 400cd/m2 / 250cd/m2
Taxa de contraste: 800:1/3000:1
Viewing Angle: (L) 85 / (R) 85 / (T) 50 / (B) 80 / (L) 89 / (R) 89 / (T) 89 / (B) 89
Touchscreen Type: Capacitive Touchscreen
Transmittance: ≥ 87%
Controller interface: USB
Compatibilidade driver: Windows 7, Windows 8, Windows 10, Linux
Response Time: < 5 ms
Surface hardness: Mohs Hardness 7H
Click life: 250g / 100,000,000 times
Multi-touch: 10 points (windows system)
Dimensões : 405mm x 258mm x 74mm
Tamanho de recorte: 387mm x 240mm
Peso: 4.7kg
Cor: Silver
Sistema de refrigeração: Fan
Compatibilidade: Windows 7, Windows 7 Embedded, Windows8, Windows 10, Ubuntu, VXWORKS, QNX
Tensão de entrada: 12-24VDC ±10%, Support reverse connection protection, over voltage protection, over current
Consumo: 28Watt (modo de repouso)
Temperatura a funcionar: 0 ~ 50°C
Storage temperature: -20 ~ 60° C
Humidade relativa: 5 ~ 95% RH@40°C (Non-condensation)
Vibration: Operating Random Vibration Test 5~500Hz, 1.5Grms@with SSD, follow IEC 60068-2-64
Shock: Operating 20G peak acceleration (11ms duration), follow IEC 60068-2-27
EMC: CE/FCC Class B
Water-proof: Front panel IP65
Expansion Slot
MiniPCIe: 1×Mini-PCIe slot, extensible 3G, WIFI wireless card
