Powerful Processor: Rockchip RK3399 6-core 64-bit CPU with Mail-T860 MP4 image processor.
Clear & Responsive Display: 10.1″ TFT screen, 1280×800 resolution, capacitive touch.
Dual OS Support: Android and Ubuntu for versatile performance.
Rugged & Durable: Aluminum-magnesium alloy, IP65 front panel, fanless design.
Flexible Power: Supports DC 12V-24V input.
Easy Mounting: VESA and Panel Mount options available.
LAN: 2x 10/100/1000Mbps Ethernet ports.
USB: 3x USB 2.0, 1x USB 3.0.
COM Ports: 4x RS232 (DB9), configurable RS485/TTL.
Audio: 2x 3.5mm speaker jacks, 1x optional MIC IN.
Wi-Fi: 2.4G Wi-Fi, Bluetooth 5.0.
Other: 1x USB OTG, 1x MiniPCIe for 4G LTE/5G module (reserved).
HDMI: Supports 4K @60Hz, HDCP 1.4/2.2.
Size: 10.1″ TFT LCD.
Resolution: 1280×800, 350cd/m² brightness.
Touchscreen: Multi-point capacitive touch (up to 10 points), 7H surface hardness.
MTBF: 30,000 hours.
Dimensions: 269.16mm x 187.8mm x 40.8mm.
Weight: 1.17kg.
Mounting: VESA and Panel Mount.
Input Voltage: 12-24V DC.
Support: Android 7.1.2, Ubuntu 18.04.
Operating Temperature: -20°C to 60°C.
Storage Temperature: -30°C to 80°C.
Humidity: 5-95% RH (non-condensing).
Vibration & Shock Resistance: 1.5 Grms, 10G shock (IEC 60068-2-64).
Waterproof: Front panel IP65.
EMC: CE/FCC Class B.
