Full IP65 Protection: Dustproof and waterproof, ensuring robust performance in challenging environments.
Capacitive Touch Screen: High-sensitivity interface for precise operation.
High-Quality Operation Keys: Durable keys with customizable options for text, color, and logo.
Connector Compatibility: Supports various cantilever profile connections for versatility.
Efficient Installation: Simplified maintenance with core components easily accessible.
Customizable Front Panel: Flexible configurations for keys, switches, and indicators tailored to your needs.
Expansion Capabilities: Options for USB, host switches, Wi-Fi, and additional functions.
LAN: 2 x Intel 1000Mbps RJ-45 Ethernet.
USB: 4 x USB3.0/2.0/1.1.
COM: 2 x RS232/RS485 with surge protection and automatic flow control for RS485.
Audio: Optional.
Size: 18.5″ HD TFT.
Resolution: 1366 x 768.
Backlight: LED, MTBF 30,000 hours.
Brightness: 250cd/m².
Viewing Angle: (L) 85° / (R) 85° / (T) 80° / (B) 80°.
Type: Capacitive touch, multi-touch support.
Dimensions: 593mm x 372mm x 139.5mm.
Weight: 10.24KG.
Optional Features: Keyboard tray, operation buttons, and pensile direction (up or down).
Fixed Stand: Compatible with the entire series.
Handle: Standard operation panel handle.
Input Voltage: DC 12-24V with reverse polarity, overvoltage, and overcurrent protection.
OS: Supports Windows 7/8/10 and Linux.
Operating Temperature: -10 ~ 60°C.
Storage Temperature: -20 ~ 80°C.
Humidity: 5~95% non-condensing.
Vibration: Random vibration, 1.5Grms (SSD), IEC 60068-2-64.
Shock: 20G peak, 11ms duration, IEC 60068-2-27.
Compliance: CE/FCC Class B.
Waterproofing: IP65.
