Processor: Intel® Core™ 6th-11th Gen i7 / i5 / i3 / Pentium® / Celeron®, LGA1151, MAX TDP 35W.
Remote Transmission: Supports up to 100 meters between PC and display/HMI.
Networking: 3 × Intel GbE LAN, 1 × eLINK LAN for data transmission.
Connectivity: 4 × USB 3.0, 2 × RS-232/485 ports.
Expansion: Options for 1 × PCIe x16 or 1 × PCI slot.
I/O Interfaces: Includes DVI-D, LAN, USB, eLINK port, RS-232/485, and PCIe.
OS Compatibility: Windows 7, Windows 10, Windows 11, and Linux.
LAN: 3 × Intel GbE LAN controller, 1 × eLINK LAN port for data transmission
USB: 4 × USB 3.0 / 2.0 / 1.1
COM: 2 × RS232 / 485 selectable
VGA: Requires a DVI-D to VGA adapter
DVI: Supports 1920 × 1080
HDMI: Requires a DVI-D to HDMI adapter
Dimensions: 238mm × 191.5mm × 120mm
Weight: 3.5 kg
Mount: Supports desktop and wall-mounted mounting
Input Voltage: DC 12~24V ±10%
OS: Windows 10, Linux
Operating Temperature: -20 ~ 60°C (-4℉ ~ 140℉) with wide temperature SSD; 0 ~ 45°C (32℉ ~ 113℉) with general temperature HDD/SSD
Storage Temperature: -40 ~ 80°C (-40℉ ~ 176℉)
Relative Humidity: 5~95% (Non-condensation)
Vibration: Operating Random Vibration Test 5~500Hz 1.5Grms with SSD following IEC 60068-2-64
Shock: 20G peak acceleration (11ms duration), following IEC 60068-2-27
EMC: CE/FCC Class A
