Protection: Full IP65 dustproof and waterproof.
Touch Screen: Capacitive or resistive flat touch options.
Operation Keys: High-quality keys and indication switches.
Connectivity: Supports various cantilever profiles.
Installation: Simple site setup with visible core components for easy maintenance.
Customization: Front panel keys customizable for LOGO, text, and colors.
Expandability: USB, host switch, Wi-Fi, and custom function support.
Controller Integration: Easy connection for front panel operation keys and switches.
LAN: 2× Intel 1000Mbps RJ-45 Ethernet
USB: 4× USB 3.0/2.0/1.1
COM: 2× RS232 / RS485 with surge protection and automatic flow control
Audio: Optional
Size: 19″ SXGA TFT
Resolution: 1280 × 1024
Brightness: 250cd/m²
Contrast Ratio: 1000:1
Touch Screen: Capacitive, 10-point multi-touch
OS: Windows 7/8/10 and Linux
Operating Temperature: -10 ~ 60°C
Storage Temperature: -20 ~ 80°C
Humidity: 5–95% (non-condensing)
Shock & Vibration Resistance: Meets IEC 60068 standards
Waterproof: Full IP65 rating
EMC: CE/FCC Class B
