Intel® 10th Gen Core / Pentium / Celeron Desktop CPU Support,
LGA1200Max CPU TDP: Deca-Core 125WIntel® Q470 Chipset
2 x Intel GbE LAN Controllers
Extensive I/O Options: 1×RS232 (COM1), 3×RS232 (COM2/5/6), 1×RS232/RS422/RS485 (COM3), 1×RS232/RS485 (COM4)
Mini PCI-E Slot: Supports Wi-Fi, 4G/3G, with Full-Size SIM Card Slot
Expansion Slots: 3×PCIe x4, 1×PCIe x16, 2×PCI 32-bit
Storage: 1×M.2 (NGFF) Key-M, PCIe x4 NVMe/SATA Auto Detect
CPU: Supports Intel® 10th Generation Core/Pentium/Celeron Desktop CPU, LGA1200
Max CPU TDP: Deca-Core 125W
Chipset: Intel® Q470
Memory Architecture: Supports DDR4 at speeds 2400/2666/2933MHz
Memory Capacity: Up to 128GB
DIMM: 4 x Non-ECC U-DIMM slots
Expansion PCIe: 3 x PCIe x4, 1 x PCIe x16, 1 x PCIe x16 (X8 signal)
Expansion PCI: 2 x 32-bit PCI slots
Expansion MiniPCIe: 1 x Mini PCI-E Slot (WIFI/4G/3G) with 1 Full-Size SIM Card Slot
SSD: 1 x full-size mSATA SSD
HDD: 1 x 2.5″ HDD, 1 x 3.5″ HDD Bay
LAN: 2 x Intel GbE LAN controllers
USB: 4 x USB3.0 (Rear IO), 2 x USB3.0 (Header), 2 x USB2.0 (Rear IO), 4 x USB2.0 (Header)
COM: 1 x RS232 (DB9/M), 3 x RS232 (Header), 2 x RS232/RS422/RS485
PS2: 1 x PS2 Port (Keyboard & Mouse)
Audio: Optional
Graphics Engine: DirectX 11, OpenGL 3.1, OpenCL 1.1 support
VGA: 1920×1200@60Hz
DVI: 1920×1200@60Hz
HDMI: Supports max resolution 4096×2160@30Hz
Dual Display: Supports VGA + HDMI + DVI
Dimensions: 481mm x 430mm x 177mm
Weight: 9.62kg
Mounting: 19″ Standard rack-mount IPC
Power: Input Voltage – ACV180~264V or AC200~240V
Work Temperature: -20 ~ 60°C (with solid-state drive)
Storage Temperature: -40 ~ 80°C
Humidity: 5~95% (Non-condensation)
Vibration: 1.5 Grms (IEC 60068-2-64)
Shock: 10 G (IEC 60068-2-64)
EMC: CE/FCC Class B
