Supports Intel® Core™ processors (6th/7th/8th/10th/11th Gen) with max TDP of 65W
Dual Intel GbE LAN controllers
PoE support for network reliability
USB 3.0 and USB2.0 Type-A for expansion
RS232/RS485 with auto flow control
Supports DVI-D and HDMI display outputs
MiniPCIe slot for WiFi or 3G/4G modules
32 isolated DIO (16 x DI, 16 x DO)
DC12~24V power supply with protection against overcurrent, overvoltage, and polarity inversion
Operates in -20°C to 60°C temperature range
Intel® Celeron® J6412 processor (2.0GHz up to 2.6GHz), TDP 10W
Chipset: Intel® SoC integrated
Memory: Single Channel DDR4 3200MHz, up to 32GB
Memory Capacity: 1 x DDR4 260-pin SO-DIMM slot
Storage Medium: 1 x SATA3.0 port, 1 x M.2-2242 B Key SSD slot (SATA3.0)
Graphics: Intel® UHD graphics integrated
Audio: Realtek ALC897 codec
Expansion Slot 1 x M.2-2230 E Key slot for Wi-Fi module (PCIe/USB2.0)
Expansion Slot 1 x Mini-PCIe slot with Nano-SIM socket (PCIe/USB2.0)
1 x LVDS dual channel (up to 1920×1200@60Hz)
1 x eDP1.3 (up to 4096×2160@60Hz)
1 x Audio wafer (Mic-in/Line-out 2*5pin)
2 x USB2.0 wafer
1 x RS232/RS485 wafer, 1 x RS232 wafer, 4 x TTL wafer
1 x Smart Fan wafer
1 x SMbus wafer
1 x Front panel wafer
1 x 8bit GPIO
Dimensions: (L)146mm x (W)102mm
Weight: 0.8kg
Input: 12~24V DC with ±10% tolerance
Support: Windows 7/10, Linux
Operating Temperature: -10°C ~ 60°C with SSD
Storage Temperature: -40°C ~ 85°C
Relative Humidity: 5~95% (Non-condensing)
Vibration: 5~500Hz, 3Grms operating
