Support: Intel® Celeron™ J1900/J6412
LAN: 3 x GbE LAN controller
USB: 1 x USB3.0, 2 x USB2.0
COM: 1 x RS232, 1 x RS485
Expansion: 1 x miniPCIe slot, supports WiFi, 3G/4G modules
LED: 1 x Programmable LED
Display: HDMI/DP
Power: DC12~24V with overcurrent, overvoltage, and polarity inverse protection
Mounting: Wall-mounted or DIN-Rail
Temperature: -20 ~ 60°C operational range
LAN: J1900: 2 x RTL8111H GbE LAN, 1 x Intel GbE LAN / J6412: 3 x Intel GbE LAN
USB: J1900: 1 x USB3.0, 2 x USB2.0 / J6412: 3 x USB3.1
COM: 1 x RS232, 1 x RS485
DO: 1 x Programmable LED
DP: J1900: Up to 2560 x 1600 @60Hz / J6412: Up to 4096 x 2160 @60Hz
HDMI: J1900: Up to 1920 x 1080 / J6412: Up to 3840 x 2160 @60Hz
Dimensions: (L)138mm x (W)102mm x (H)48mm
Weight: 1.06Kg
Box Structure: Aluminum-magnesium alloy, Fanless
Input Voltage: DC12/24V ±10%, with overcurrent, overvoltage, and polarity
Microsoft Windows: Windows 10
Linux: Ubuntu
Work Temperature: -20ºC ~ 60ºC (-4℉~140℉) with air flow (SSD)
Storage Temperature: -40ºC ~ 80ºC (-40℉ ~ 176℉) with air flow (SSD)
Relative Humidity: 5~95% (non-condensing)
Vibration: 5~500Hz, 1.5Grms@with SSD, Follow IEC60068-2-64
Shock: 20G peak acceleration (11ms duration) with SSD, Follow IEC60068-2-27
EMC: CE/FCC Class B
