Processor: Intel® Celeron® J1900, Quad-core, 2.0GHz base frequency, TDP 10W
Memory: 1 x DDR3L-1333MHz SO-DIMM slot, up to 8GB
Graphics: Supports VGA, HDMI, LVDS/eDP Dual-display
Networking: 2 x Giga-bit Ethernet
USB Ports: 1 x USB3.0, 5 x USB2.0
Serial Ports: 1 x RS232/485, 1 x RS232, 4 x TTL
Expansion: 1 x M.2-2242, 1 x Mini-PCIe slot with nano-SIM card socket
Power: 12~24V DC input, lockable DC-IN phoenix terminal block
CPU: Intel® Celeron® J1900, 2.0GHz
Chipset: Intel® SoC integrated
Memory: DDR3L 1333MHz, up to 8GB (1 x DDR3L SO-DIMM slot)
Storage medium: 1 x SATA2.0 port, 1 x M.2-2242 M Key SSD slot (SATA2.0)
Controller: Intel HD graphics integrated
Codec: Realtek ALC897 codec
Display: 1 x VGA, 2560×1600@60Hz; 1 x HDMI, 1920×1080@60Hz
Ethernet: 2 x GbE (RJ45)
USB: 1 x USB3.0, 1 x USB2.0
Button: Power button (White: Power on, Blink: Sleep, Off: Off)
Indicators: SATA LED (Red), Power LED (Green)
Audio: 1 x Audio wafer (Mic-in/Line-out, 2*5pin)
USB: 2 x USB2.0 wafer (14pin), 2 x USB2.0 wafer (1 x 25pin)
COM: 1 x RS232/485 wafer (25pin), 1 x RS232 wafer (25pin), 4 x TTL wafer (2*8pin)
Fan: 1 x Smart Fan wafer (1*4pin)
SMbus: 1 x SMbus wafer (1*4pin)
LPC: 1 x LPC header for debug
GPIO: 1 x 8bit GPIO (2*5pin)
Others: Front panel wafer (Power LED, HDD LED, Power button, Reset button)
Display: 1 x LVDS, dual-channel 18/24bit, 1920×1200@60Hz; 1 x eDP1.3, up to 3840×2160@60Hz
Dimensions: 146mm x 102mm
Weight: 0.8kg
Input: 12~24V DC (+/-10% tolerance)
Support: Windows 7/10, Linux
Operating Temp: -10°C to 60°C (with SSD)
Storage Temp: -40°C to 85°C
Humidity: 5~95% (Non-condensing)
Vibration: 5~500Hz, 3Grms operating
