Aluminum-magnesium alloy box, Front panel IP65
Ecrã tátil capacitivo 10.4″ XGA TFT, com resolução de 1024*768
Support Intel® Celeron® J6412 / J1900 / Core™ i5 7200U
2x Gigabit Ethernet ports, 2x RS-232 COM, 8KV electrostatic protection, 600W TVS surge protection, RS485 support automatic flow control
Wide voltage power supply：DC12~24V.Support reverse polarity protection, overvoltage protection, overcurrent protection
Extend WIFI/3G/4G network/1 x Mini-PCIe slot/1 x EasyBUS slot
Fanless design, VESA Mount, Panel Mount
I/O: VGA / DVI / 2GLAN / 4USB / 2COM / AUDIO
LAN: 2 x Intel i211 1000Mbps RJ-45 with surge protection, lightning protection design and 15KV ESD protection
USB: 4 x USB3.0/2.0/1.1
COM: 2 x RS-232/RS-485 with surge protection, RS485 support automatic flow control
Audio: Realtek ACL662 Audio controller
Rear I/O: DVI-D / 2 x GLAN / 4 x USB / 2 x COM /2 x PS2 / Line-out/Mic-in
LCD Size: 10.4″ XGA TFT
Resolução: 1024 x 768
Cor: 16.7MB
Active Area: 211.2mm×158.4mm
Backlight: LED
MTBF: 30000hrs
Pixel Pitch: 0.206×0.206
Luminance: 350cd/m2
Contrast Ratio: 900:1
Viewing Angle: (L) 75 / (R) 75 / (T) 75 / (B) 75
Touchscreen Type: Multi-point capacitive touch screen
Transmittance: > 87%
Controller interface: USB
Driver Support: Windows 7, Windows 8, Windows 10, Linux
Surface hardness: Mohs’ 7H
Multi-touch: 10 points (windows system)
Dimensões : 298.5mm×238.5mm×65mm
Tamanho de recorte: 280.5mm×220.5mm
Peso: 3.46kg
Compatível com: Windows 7, Windows 7 Embedded, Windows 8, Windows 10, Ubuntu, QNX, VXWORKS
Tensão de entrada: 12-24VDC ±10%, suporta proteção de polaridade reversa, proteção contra sobretensão e proteção contra sobre corrente
Poder de dissipação: 35W (Máximo)
Temperatura a funcionar: -20~6°C (-4~140°F)
Storage temperature: -30 ~ 80°C (-22 ~ 176°F)
Relative Humidity: 5~95%@40°C (non-condensing)
Vibration: SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock: SSD applied: 10 G, IEC 60068-2-27, Half-sine wave, 11ms duration
EMC: CE/FCC Class B
Water-proof: Front panel IP65
Expansion Slot
MiniPCIe：1×Mini-PCIe slot, extensible 3G, WIFI wireless card; 1×EasyBUS slot
