Modular Design: Supports Intel 6th to 11th Gen CPUs, including 10th/11th Gen CPUs.
Dual LAN: 2 × Realtek GbE LAN for reliable networking.
Comprehensive USB Options: 4 × USB 3.0, 2 × USB 2.0, plus 1 × USB 2.0 dongle built-in.
Flexible COM Ports: 2 × RS232/RS485 and 4 × RS232 ports for diverse connectivity.
PCI Expansion: Options for 1 × PCIe X16 + 2 × PCIe X1 or 1 × PCIe X16 + 2 × PCI.
Multiple Display Ports: Supports HDMI and VGA outputs
Expandable with MiniPCIe: 2 × MiniPCIe slots for 3G/4G modules.
Storage Flexibility: 1 × 2.5″ SATA and 1 × M.2 disk interface, compatible with SATA disks.
Durable Power Input: DC 12-24V with overcurrent, overvoltage, and anti-reverse protection.
Wide Operating Temperature: Designed to perform in environments ranging from -20°C to 60°C.
LAN: 2 × Realtek GbE LAN controllers
USB: 4 × USB 3.0, 2 × USB 2.0
COM: COM1–COM2: RS232/RS485, COM3–COM6: RS232
VGA: 1920 × 1200@60Hz
HDMI: 4096 × 2160@30Hz
Dimensions: (L) 230mm × (W) 192mm × (H) 154mm
Weight: 3.6kg
Box Structure: Aluminum-magnesium alloy box
Cooling System: Fanless
Mount: Wall-mounted
Input Voltage: DC 12–24V, with overcurrent, overvoltage, and reverse polarity protection
Microsoft Windows: Windows 10 IoT, Windows 11
Linux: Ubuntu
Work Temperature: -20 ~ 60°C (-4 ~ 140°F) with airflow (mSATA)
Storage Temperature: -40 ~ 80°C (-40 ~ 176°F) with airflow (mSATA)
Relative Humidity: 5 ~ 95% (non-condensing)
Vibration: Operating Random Vibration Test 5 ~ 500Hz, 1.5Grms with SSD (IEC 60068-2-64)
Shock: Operating 20G peak acceleration (11ms duration) (IEC 60068-2-27)
EMC: CE/FCC Class B
