Painel de Alumínio em conformidade com o IP65
Ecrã tátil capacitivo de 21.5″ Full HD TFT, com resolução de 1920*1080
Disponível Intel® the 6th – 11th Gen. Core™i3/i5/i7, Pentium, Celeron LGA1151 socket CPU
3x Portas Ethernet Gigabit
4 x RS-232 / RS-485 Interface with surge protection, RS485 support automatic flow control
Wide voltage DC12~24V input, reverse polarity protection, overvoltage protection, overcurrent protection
Extend WIFI/3G/4G network from Mini-PCIe slot
I/O: HDMI/ 3GLAN /6USB / 4COM
LAN: 3×Intel 10/100/1000Mbps controller
USB: 4 x USB3.0 / 2 x USB2.0
COM: 4 x RS-232 / RS-485 Interface with surge protection, RS485 support automatic flow control
DI: 8DI+8DO, Wet contact input(24V), OC gate output (24V 300mA)
DO: 8DI+8DO, Wet contact input(24V), OC gate output (24V 300mA)
Rear I/O: DVI-I / 2 x GLAN / 4 x USB / 2 x COM /2 x PS2
LCD: 21.5″ Full HD TFT
Resolução: 1920 x 1080
Cor: 16.7MB
Active Area: 476mm×268mm
Backlight: WLED
MTBF: 50000hrs
Pixel Pitch: 0.248 x 0.248
Luminância: 250cd/m2
Taxa de contraste: 1000:1
Viewing Angle: (L) 89 / (R) 89 / (T) 89 / (B) 89
Tipo de ecrã: Ecrã tátil capacitivo (sensível ao toque em vários pontos)
Transmittance: > 87%
Controller interface: USB
Compatibilidade do Driver: Windows 7, Windows 8, Windows 10, Linux
Response Time: < 5 ms
Surface hardness: Mohs’ 7H
Click life: 250g / 100,000,000 times
Multi-touch: 10 points (windows system)
Dimensões: 550mm×342mm×74mm
Tamanho de recorte: 533mm×325mm
Peso: 6.9kg
Cor: Cinza/Prateado
Sistema de refrigeração: Fan
Compatível com: Windows 7, Windows 7 Embedded, Windows 8, Windows 10, Ubuntu, VXWORKS, QNX
Tensão de entrada: 12-24VDC ±10% , com proteção contra conexão reversa, proteção contra sobretensão e proteção contra sobre corrente.
Temperatura a funcionar: -20 ~ 60°C (-4~140°F) (Wide temperature SSD) / 0 ~ 45°C (32~113°F) (General temperature HDD/SSD)
Storage temperature: -30 ~ 80°C (-22~176°F)
Humidade relativa: 5 ~ 95% RH@40°C (Non-condensation)
Vibration: Operating Random Vibration Test 5~500Hz, 1.5Grms@with SSD, follow IEC 60068-2-64
Shock: Operating 20G peak acceleration (11ms duration), follow IEC 60068-2-27
EMC: CE/FCC Class B
Water-proof: Front panel IP65
Expansion Slot
MiniPCIe: 1×Mini-PCIe slot, extensible 3G, WIFI wireless card
